Station Equipment Inventory and Status - PJ2T
| Caribbean
Contesting Consortium Station Equipment Inventory and Status - PJ2T |
|
|
| Transceivers | Linear Amplifiers | Computer Items | Antennas and Towers | Station Accessories | Rotators | Transmitting Tubes |
| Item | Currently in Use at Station Number: | Status | Location | Notes |
FT-1000
MP (1) INRAD roofing filter 9 Sept 05 K9AN AF filter mod 9 Sept 05 8215 KHz IF: 455 KHz IF: Subreceiver: |
Operational | PJ2T | Manual Installed INRAD roofing filter and K9AN AF filter mod 9 Sept 2005 RX 20 dB deaf - returned to US for service 31 Oct 2006 Repairs complete January 2007 and transported to Curacao by W8WTS 22 Jan 2007. Click here for repair invoice. Receiver deaf CQWW SSB 2008 Repaired November 2008. Click here for repair invoice. |
|
FT-1000 Mark V Field (6) INRAD roofing filter 70.455 MHz 8215 KHz IF: 455 KHz IF: Subreceiver: |
Operational | PJ2T | FT-1000 Mark V Field Manual Acquired 2 June
2006 March 2008 -- low output (30 watts) on 10, 15, 20. K9SG hauled to States and sent to WA4GEG, returned May by WI9WI. |
|
FT-1000 MP (7) Roofing Filter: None 8215 KHz IF: 455 KHz
IF: Subreceiver: |
Display Inop | PJ2T |
FT-1000 Mark V Field Manual
Acquired November 2008 new on EBay. October 2015 no display. Repaired (W0CG) December 2016 but only lasted 10 minutes. Leave in Cur until new inverter board is available. |
|
FT-2000
(1)
|
Operational | PJ2T |
Won at W9DXCC 2008. Sold/donated to CCC by K9SG. |
|
FT-2000
(2) |
3 | Operational | PJ2T | New from Yaesu 6 Nov 2009. |
FT-2000
(3) |
Operational | PJ2T | New from Yaesu April 2010. |
|
|
Elecraft K3 (1) SN 0157 (100% K8WDN (SK) gift) |
Operational | PJ2T | ||
|
Elecraft K3 (2) SN 8714 (50% KB7Q gift) 400Hz 8 pole filter |
Operational | PJ2T Dedicated Remote Station |
Repaired December 2016 by N7IR K3 Hardware Configurations - N7IR |
|
|
Elecraft K3 (3) SN 101 (CCC purchase) |
Operational | PJ2T | Bought December 2017 | |
|
Elecraft K3 (4) SN 1763 (Gift from W1FJ) |
Operational | PJ2T | Donated July 2018 | |
|
Elecraft K3 (5) SN 4829 (Gift from KE7X estate) |
Operational | PJ2T | Donated June 2019 | |
|
Elecraft K3 (6) SN 8079 (Donation from N7NR) |
Operational | PJ2T |
Donated November 2021 by N7NR, purchased from K6RO K3 Hardware Configurations - N7IR |
|
|
Elecraft K3 (7) SN 8323 (CCC purchase) |
Operational | PJ2T | Purchased from W4NPD November 2021 | |
|
Elecraft K3 (8) SN 734 (CCC purchase) |
Operational | PJ2T | Purchased from W3NA December 2022 | |
|
Elecraft K3 (9) SN 10602 (CCC purchase) |
4 | Operational | PJ2T | Purchased by N7IR August 2023 |
| IC-765
(W8TK) SN 01956 CW Filters: Yes Serial Interface: Built In |
Inop | PJ2T | Has W1GEE interface cable
bought by N8BJQ and NW0L homebrew interface. Both work.
October 2008 RX reported deaf but problem could not be replicated. Moved from Stn 4 to reserve, in desiccant bag, Oct 2009. Inop March 2013 |
|
| IC-765 (N8BJQ) SN 01952 CW Filters: Yes Serial Interface: Built In |
Operational | PJ2T | W0CG picked up in May from N8BJQ and shipped to W6XA for repair. Taken to Curacao October 2005 by N4RV. | |
| Omni VI w/ Model 280 DC supply (W8TK) SN 12A10033 CW Filters: INRAD and Ten-Tec #221 Serial Interface: Built In |
Operational | PJ2T | Notes
Returned to States for repair in July 2006, back on Curacao October 2006. |
|
FT-1000
MP (2) INRAD roofing filter K9AN AF filter mod Apr 05 8215 KHz IF: 455 KHz IF: Subreceiver: |
Decommissioned | W8TK | Manual
21 Oct 09 Main RX sensitivity 20dB down on 40 and 80 (K6AM). Returned to States Dec 2009 for repair and retirement. Repaired- and awaiting sale mid-Jan 2010. |
|
FT-1000 Mark V Field (3)
INRAD roofing filter 9 Sept 05
K9AN AF filter mod installed
8215 KHz IF:
455 KHz IF:
Subreceiver: |
3 | Inop and decommissioned for salvage. | W0CG May 2018 |
FT-1000 Mark V Field Manual
Repaired by Yaesu March 2003. Returned to PJ2 on 10 July 2003. Dead display repaired in Curacao April 2005. Installed INRAD roofing filter 9 Sept 2005. Repaired by WA4GEG Sept 2007. Main RX sensitivity way down -- Sub RX OK, TX OK and bad display inverter board. |
FT-1000 MP (4) INRAD roofing filter removed January
2007 - failed
K9AN AF filter mod 9 Sept 05
8215 KHz IF:
455 KHz IF:Yaesu XF-110CN
Subreceiver: TCXO board installed |
Inop - Decommissioned; now parts radio | Jerry's for parts source, permanently decommissioned. | Manual
Transported to PJ2 on 9 July 2003. Roofing filter added February 2005. Installed K9AN AF filter mod and repaired dead antenna Port "A" 9 Sept 2005. RX 20 dB deaf - returned to U.S. for service by W0CG 2 Nov 2006. Shipped to W6XA 2 Jan 2007. Repaired January 2007 Returned to Curacao by N1ZZ 13 Feb 2007. Still inop in transmit. Repaired and returned to W0CG 4 May 2007. Transported to Curacao 19 Oct 2007. Display failed partially Nov 2008. Repaired March 09. 21 Oct 09 Main RX sensitivity 20dB down on 40 (K6AM) RX dead Feb 2013. Badly damaged in shipping to K8LEE. |
|
FT-1000 Mark V Field (5)
INRAD roofing filter 9 Sept 05
K9AN AF filter mod installed
8215 KHz IF:
455 KHz IF: |
3 | Inop |
N7IR / Arizona. Sold for salvage November 2017 |
FT-1000 Mark V Field Manual
Display failed Mar 2010, taken to svc by K8LEE. Repaired April 2010. Low RF output 160, 80; Feb 13. Repaired May 2013 Hangs up in xmit, VERY low output except on 15. |
| TS-930 (W9VA) SN 7090017 CW Filters: Yes Serial Interface: No |
Inop | PJ2T | Needs new power switch -- parts are on site at PJ2T; RF output control is highly nonlinear. 18 July 2009 inop. Comes on but no functionality. W9VA approved disposal February 21 2011. | |
| IC-505 (W9JUV) SN 01376 |
Operational | PJ2T | Shipped to W9JUV 21 Oct 02 for evaluation and repaired. Now in reserve at PJ2T. | |
| Kenwood
TS-60 6 Meter All Mode XCVR (WB9Z) SN 61000120 |
Operational | N7IR sold September 2017 for $300 returned to CCC Treasury. | Brought by WB9Z 5 December 2006. Moved into desiccant bag Oct 2009. Shipped to N7IR for salvage 1 Aug 17. | |
| TS-930 (W8TK) SN 4120344 CW Filters: IRC 400 Hz 1st and 2nd IFs Serial Interface: Piexx SN 05032002B30-RC installed 20 Aug 2002 by W0CG |
Operational | K8LEE | Occasionally the PLL unlocks.
Turning rig off and back on resets it OK. VFO will not change freq. All else works. K8LEE took to US February 22, 2011. Repaired and retired from PJ2T. |
|
| TS-940 (W0CG Wooster Zilko radio) SN 7080140 CW Filters: 400Hz IRC Serial Interface: Yes |
Partially Inop | Retired to Idaho, then stolen in a house burglary. | Drifts in
transmit since Piexx mod was installed. 50 watts output, maximum. April 2005: TX drift seems corrected, output low at 50 watts. Operational November 2005. |
|
| Yaesu FT-211RH 2 meter FM radio (W8TK) |
2 Meters | Operational | PJ2T | |
| Icom IC-228 2 meter FM radio (K9SG) | 2 Meters | Operational | PJ2BR | Given to PJ2BR in November for the PacketCluster |
|
Yaesu FT-8800R 2M/440 FM Transceiver SN 4F170783 (NT6X) |
2
Meters 440 MHz |
In Test | PJ2T | GIft from NT6X November 2016 |
|
Yaesu FT-2900R 2 meter transceiver SN 0J130856 |
2 Meters | Operational | PJ2T | Bought and installed by N7IR November 2017 |
| TS-440 (W8TK) CW Filters: No Serial Interface: No |
Partially operational -- sometimes drifts. | W0CG (Ohio) | In States at W0CG awaiting decision on repair | |
| Yaesu FT-100D (WB9Z) SN 2F330012 |
Inop | W9JUV | In reserve | |
| TS-940 (W0CG K3TUP radio) SN 9090115 CW Filters: Kenwood YK-88C1, Kenwood YG-455C-1 Serial Interface: Piexx installed 10 Oct 02 by W0CG |
Inop | Jahnke Electronics for salvage value Sept 2017 | Repaired March 2002 by Groton Electronics -- many opened solder connections on most of the boards. As of November 2002 has PLL problem -- display goes to all dots 1 second after powerup. Repaired again in October 2003 by Groton electronics. Retained at W0CG as inoperable in tropical climate. | |
| TS-940 (W8TK) SN 8070262 CW Filters: One 8655 IF Serial Interface: Piexx, installed by W0CG November 2002 |
Inop | Jahnke Electronics for salvage value Sept 2017 | Acc DIN jack on
back is smashed -- can't (now or ever) hook up Beverage input. Dead - won't come on as of April 2005. Spare parts. Returned to U.S. December 12, 2007, for salvage. |
| Item | Currently in Use at Station Number: | Status | Location | Notes |
| AL-1200
(1) (CCC owned) SN unknown. Paper tag is scratched off. |
Operational | PJ2T | New filament transformer and auxiliary cooling fans installed February 2002 (W8AV and N8LGP). As of 10 July 2003 only 50 to 100 watts out on any band. Tube brought to U.S. 23 July 2003 and found to be bad. New tube installed 10 Sept 2003. | |
| AL-1200 (2) (CCC owned) SN AL 12-12338 February 2009 |
4 | Operational | PJ2T | Bought February 2009 in Wheeling,
WV by K8ND.
Transported to Curacao March 2009 by K8LEE. |
| AL-1200 (3) (CCC owned) SN AL 12-12541 December 2009 |
Operational | PJ2T | Bought November 2009 from K8NU, Columbus, Ohio. | |
| AL-1200 (4) (CCC owned) SN AL 12-12536 June 2011 |
Operational | PJ2T | Bought June 2011 from K7WM, Cibola, AZ, by W0CG. | |
|
AL-1200 (5) (CCC owned) SN AL 12-12354 February 2013 |
2 | Operational | PJ2T | Bought February 2013 at Case Western. |
|
AL-1200 (6) (CCC owned) SN AL 12-12392 March 2018 |
Operational | PJ2T | Bought March 2018 from K4JRS, Atlanta, SK estate. | |
|
AL-1200 (7) (CCC owned) SN AL 12-11705 September 2019 |
Operational | PJ2T | Gift from Art Brown, W3KHZ/VY2MM (SK) through K2PLF. | |
|
AL-1200 (8) (CCC owned) SN AL 12-12184 November 2021 |
Operational | PJ2T | Bought from PJ2BR | |
|
Command Technologies HF-2500 (CCC
owned) SN 485 March 2020 (NR0X) |
1 | Operational | PJ2T | Gift from
NR0X Notes |
|
Ten-Tec Titan
III Linear SN 01C10094 September 2006 (W8TK) |
Mostly Inop - 400 watts output only | PJ2T |
Donated 2 June 2006 to CCC by
W8TK. Notes |
|
| LK-800
(CCC owned) SN 902904 |
3 | Operational | PJ2T | Needs tube # 3 3CX800A7 (running now with two of the needed three tubes); also needs new #3 parasitic suppressor -- parts are at Signal Point. |
| Alpha 76A linear (WI9WI) SN 5921 | Operational | PJ2T | New 8874 tubes installed February 2002 by W0NB and W9EFL. Full output on all bands. Notes | |
| Alpha 76A linear, SN 5417 (CCC owned) ("Arizona") | Operational | PJ2T | Tested good by K8ND. Notes | |
| Ten-Tec Titan I (425) SN 94A10228 |
Operational | PJ2T | Conditionally acquired from
VERONA April 2005. Taken to U.S. for evaluation at Ten-Tec April 2005. .
Repaired at factory and returned to W0CG June 2005. Further repairs completed on Curacao November 2005. New electrolytics (Feb 2008) HV blew Nov 2008, repaired Feb 2009 and again Dec 2012. Retubed Feb 2018. |
|
| K8NZ homebrew 3-500Z linear (NSN) | Inop and retired | Idaho | No 160. Grid current/HV meter intermittent. See notes. Absolutely requires XCVR antenna tuner -- amp has no input network. | |
| Centaur (W8TK) SN 08A10017 | Operational | PJ2A - VERONA | Spare set of Cetron 811As on
hand at QTH. Amp is stored in East Closet. Notes Tested OK mid-March 2005 -- full output. Bartered to VERONA September 2005 |
|
| Alpha 78 linear Photo1 Photo2 (W8TK) SN 8133 |
Operational | W8TK | Transported to Curacao by W0CG 9
July 2003. Notes December 2004: Will not turn on -- blowing main primary fuses. Replaced one tube 3 Mar 2005. OK now. Replaced K4 February 2006. Dec 2008 - Will not make RF. Suspect K4. Returned to U.S. March 2009. Repaired April 2009 and returned to W8TK permanently. |
|
| Ten-Tec Titan 2
Linear SN 10A10089 February 2002 |
2 | Operational | PJ2T | Ten-Tec long term loan, placed in service February 2002. Retired to States November 2009 for salvage value. |
| Item | Currently in Use at Station Number: | Status | Location | Notes |
| PC30
Dell
Inspiron 560 Slim Tower Bought by W0CG March 2011 |
Operational | PJ2T | Taken to Curacao March 2011. Our first Windows 7 machine Failed 1 Nov 2011 after CQWW SSB; fixed 18 Nov 2011 Inop
CQWW SSB 2012 |
|
| Acer X223WBD LCD
Monitor, 22 inch (K8ND) SIND: 90915987342 |
2 | Operational | PJ2T | Bought 28 April 2009, Staples |
| PC31
Dell
Inspiron 560 Slim Tower Bought by W0CG April 2011 |
Inop | PJ2T | Second Windows 7 machine Sept 2013 - dead, will not start. Nov 2013 starts but will not boot. |
|
| PC32
Dell
Inspiron 560 Slim Tower Bought by W0CG April 2011 |
4 | Operational | Retired | Third Windows 7 machine Hard drive failed November 2014. New drive cloned 11 June 2015 |
| PC33 Dell
Inspiron 560 Slim Tower Bought by W0CG April 2011 |
3 | Operational | PJ2T | Fourth Windows 7 machine Shipped to K8LEE 30 June 11. |
| PC34
Dell
Inspiron 560 Slim Tower Bought by W0CG June 2011 |
Operational | PJ2T |
Fifth Windows 7 machine Configured for PJ2T by W0CG, 30 June 2011. Shipped to N1ZZ 2 July 2011.
|
|
| PC35 Dell
Inspiron 560 Slim Tower Bought by W0CG June 2011 |
Operational | PJ2T | Sixth Windows 7 machine. Configured for PJ2T by W0CG, 14 July 2011. Shipped to W1BV. |
|
|
PC36 Dell Vostro 270s Slim Tower Service Tag CXDCPW1 Express Service Code 28139200273 Product Key 26RCH-WYH3D-JK98Y-DJJBD-P6DXJ Intel Core i3-3 220, 3.3 GHz, 4 GB DDR3 SDRAM 500 GB drive Bought by W0CG Jan 2013 |
Operational | PJ2T |
Seventh Windows 7 machine. Transported to Curacao Jan 2013 by W0CG |
|
|
PC 37 Fujitsu Esprimo Q9000 Model MPC-D1007 SN YL3V017533 Product Key CR4X3-KB72T-FKGKT-HJ2CR-9Y36M Intel Core i3 M 350 2.27 GHz, 4 GB RAM, 300 GB drive Windows 7 Pro SP1 Gift from SM4KYN |
Operational | PJ2T |
Eighth Windows 7 machine. Given to PJ2T 16 December 2013 |
|
|
PC 38
Dell
Inspiron 660s Slim Tower Bought by W0CG Dec 2013 |
1 | Operational | Retired |
Ninth Windows 7 machine. Transported to Curacao Jan 26 2014 by W0CG |
|
PC 39
Dell Inspiron 3647 Slim Tower Bought by W0CG September
2014 |
Operational | PJ2T |
Bought in Dell Windows 7 sale. Transported to Curacao 30 Jan 2017 by W0CG |
|
|
PC 40 Fujitsu Esprimo Q9000 Model MPC-D1007 SN YL3V017593 Product Key YFWPC-QWKJR-FR7TK-TJHPQ-WVW7Q Intel Core i3 M 350 2.27 GHz, 4 GB RAM, 300 GB drive Windows 7 Pro SP1 Gift from SM4KYN |
4 | Operational | PJ2T |
12th Windows 7 machine. Given to PJ2T 16 December 2014 |
|
PC 41 Fujitsu Model MPC-D1007 SN YL3V047008 Product Key 3Y8RV-W68GW-P8D3Q-89XB2-9BY67 Windows 7 Pro Gift from SM4KYN |
2 | Operational | PJ2T |
Given to PJ2T 14 December 2015|| Taken to Montana Nov 2016 for op sys workover by KB7Q |
|
PC42 Fujitsu Model MPC-D1007 SN YL3V032921 Product Key Q4R9M-PPJFF-D8DG2-KMPFK-FMD6P Windows 7 Pro Gift from SM4KYN |
Operational | PJ2T | December 2016 | |
|
PC43 Dell Optiplex 7040M Intel Core i5 Service Tag DB1QJG2 Express Service Code 28966216178 Windows 7 Pro Gift from SM4KYN |
Operational | PJ2T | December 2016 | |
|
PC44 Dell Optiplex 7040M Intel Core i5 Service Tag D94NJG2 Express Service Tag 28850182706 Windows 7 Pro Gift from SM4KYN |
Operational | PJ2T | December 2016 | |
|
PC45 Dell Optiplex 7040 Intel Core i5 Service Tag HXJP1H2 Express Svc Code 39033764534 (SM4KYN) |
Operational pending setup | KB7Q | December 2017 | |
|
PC46 Dell Optiplex 7040 Intel Core i5 Service Tag 85T0KF2 Express Svc Code 17765324894 (SM4KYN) |
4 | Operational | PJ2T | December 2017 |
|
PC47 Box 379 Dell Optiplex 7040 Intel Core i5 Service Tag HR8BZG2 Express Svc Code 38651882546 (SM4KYN) |
Operational | PJ2T | December 2018 | |
|
PC48 Box 409 Dell Optiplex 7040 Intel Core i5 Service Tag BWFCDH2 Express Svc Code 25905294902 (CCC purchase) |
Operational | PJ2T | November 2019 | |
|
PC49 Box 438 Dell Optiplex 7040 Intel Core i5 Service Tag 6GKWSD2 Express Svc Code 14063274902 (CCC purchase) |
1 | Operational | PJ2T | November 2021 |
|
PC50 Box 441 Dell Optiplex 7040 Intel Core i5 Service Tag 7DSJBB2 Express Service Code 16071457006 (CCC purchase) |
Operational | PJ2T |
June 2022 Anydesk 758 908 884 16 GB 256GB SSHD |
|
|
PC51 Box 442 Dell Optiplex 7040 Intel Core i5 (CCC purchase) |
Operational | PJ2T | June 2022 | |
|
PC52 Box 443 Dell Optiplex 7040M Intel Core i5 Model D10U Service Tag D5FKRD2 Express Service Code 28626654070 (CCC purchase) |
Operational - Spare Station | PJ2T |
June 2022 Anydesk 755 555 193 |
|
|
PC53 Box 444 Dell Optiplex 7040M Intel Core i5 Model D10U Service Tag D5HHRD2 Express Service Code 28629883334 (CCC purchase) |
Operational | PJ2T |
October 2022 Anydesk 558 030 987 16 GB 256GB SSHD |
|
|
PC54 Box Box 461 Dell Optiplex 7040M Intel Core i5 (CCC purchase) |
Operational ? | KB7Q | November 2022 | |
|
PC55 Box 462 Dell Optiplex 5060 i5-7500 3.4 GHz Model D10U 16.0 GB RAM 64 bit SN 80N9JL2 Anydesk 711 718 813 (CCC purchase) |
Idaho | December 2024 | ||
|
HP
M127fn_0128 Scanner/Laser Printer SN CNB9H7F91F (K8ND) |
Operational | PJ2T | Bought 5 July 2016 by K8ND | |
| PC24
Dell Dimension DIM4550 Bought by W0CG Sept 2008 |
|
Inop - no lights, scrapped 23 Nov 2017 | PJ2T | Formerly
at W0CG's home. Taken to Curacao September 2008 by W0CG. Our first XP machine used in contesting Scrapped 23 Nov 17 |
| PC25
Dell Optiplex GX150 |
|
Operational, scrapped 23 November 2017. | PJ2T | Bought
at Hamvention by W0CG May 2009.
Tests good 28 May 2009. |
| Dell S2009W Flat
Panel Monitor
20 inch |
Operational | PJ2T | Bought new 23 November
2009 - Tapirama Curacao
Partial donation by K8ND |
|
| Dell SP2309 monitor (John Shovic) | Operational, but cloudy; good for backup | PJ2T | Shovic | |
|
PC 6
PJ2T-CPQ450-NO1 |
Inop |
PJ2T
|
Notes New power supply installed 2 February 2006. Tests good 11 Feb 2009. Installed at Stn 3 February 2011, then removed with CW keying problems during Feb contest. Junked 7 February 2014 |
|
| Viewsonic VA720 17 inch flat panel monitor (CCC owned) | Operational | PJ2T | Bought using fund drive Photo | |
| PC21
Compaq
P3 650 MHz |
Operational |
PJ2T
|
Brought
to Curacao by N1ZZ Feb 2005.
Opsys regenerated Jan 2011. Spontaneously rebooted during ARRL DX CW. Now won't boot at all. OK after new power supply 2 Mar 2011 Junked 14 March 2017 |
|
| Samsung 713N 17 inch
TFT-LCD Monitor (CCC) Model: 713N Model Code: LS17MJCKS/XAA Type No: GH17LS SN MJ17HVGY907088 MJ17HVGY907088 MJ17HVGY907088 |
|
Operational | PJ2T | Bought new 3 Feb 2006, Goisco, Curacao |
| HP S 2031 20 inch
monitor SN 3CQ136NM33 (N0YY) November 2011 |
Operational | PJ2T | Donated and brought to
island 16 November 2011 by N0YY. Scrapped 23 Nov 2017 |
|
| HP S 2031 20 inch
monitor SN 3CQ1330QG9 (N0YY) November 2011 |
Operational | PJ2T | Donated and brought to
island 16 November 2011 by N0YY. Scrapped 23 Nov 2017 |
|
| Canon BJC-2100 color ink jet printer (WB9Z XYL) | 4 |
Operational but not in shack | PJ2T | Donated by Lori
Rosalius
Replaced cartridge July 2008 -- all OK. Click here for ink cartridge info Junked 7 February 2014 |
| HP
Officejet 6310 All-in-One
(W0CG) |
East Sunroom | Operational | PJ2T | Purchased
4 Feb 2009 Cartridges HP98 (black), HP 95 (color) |
| Dell
SP2309W Monitor
(W0CG) |
East Sunroom | Operational | PJ2T | New 2020 bought by W0CG, personal equipment. |
|
Dell S2440L Monitor (Shovic) |
Operational | PJ2T | Donated new February 2014 by John Shovic. | |
|
LG 22M38D-8 22 in Monitor SN 608NTTQ4A033 (NT6X) |
Operational | PJ2T | Donated November 2016 by NT6X | |
| LG 27MP59G | 1 | Operational | PJ2T | Bought Jan 2019 at Better Deals by K8ND |
|
Dell P2422H 23.8 " LED Monitor SN CN-0663YC-QDC00-1BD-3H8B-A01 Service Tag: J9320K3 Express Service Code: 41908192851 (CCC) |
Operational | PJ2T | Bought October 2022 at Better Deals by W0CG | |
| PC22
SN 6030 DKY5 B624 Compaq Desktop bought by NW0L December 2004. |
Operational |
PJ2T In "good" pile in East closet
|
Brought
to Curacao by K9SG in April 2005 12 Nov 05 COMPAQ Troubleshooting Notes Junked 14 March 2017 |
|
|
PC20
Compaq P3 650 MHz |
Inop - Won't Network |
PJ2T In "good" pile in East closet |
Brought
to Curacao by N8BJQ Feb 2005. In reserve -- needs new hard drive ASAP. Won't network. |
|
| PC10
Dell Optiplex GX110 (MMP) Bought by K8ND Sept 2005 |
|
Operational | PJ2T | Taken to Curacao October 2006 by K1XX Tests good 7 February 2014 Junked March 2017 |
| PC3
PJ2T-P3-300 MHz Pentium |
Operational | PJ2T In "good" pile in East closet
|
Notes Works fine if you F1 past the BIOS startup error message. New NIC Feb 2009. Tests good Feb 2009. Junked 7 February 2014 |
|
|
PC9
Dell Optiplex GX110 (MMP) Bought by K8ND Sept 2005 |
Inop |
PJ2T In "good" pile in East closet |
Taken to Curacao by W0CG October 2005 Junked 7 February 2014 |
|
| PC5
Compaq Presario 4505 (W8TK) |
Operational | PJ2T In "good" pile in East closet |
Installed NIC 27 Sept
02, which works OK. In reserve in Owner's Closet Tests good 11 Feb 2009. Junked 14 March 2017 |
|
| PC18
Compaq P3/933 |
|
Operational | PJ2T | Bought Feb 2004. Taken to Curacao in April by K9SG. 12 Nov 05 COMPAQ troubleshooting notes Junked 14 March 2017 |
| PC26
Dell Optiplex GX150 |
|
Inop, retired November 2017. | PJ2T | Bought
at Hamvention by W0CG May 2009.
No video Feb 2014 |
| PJ2T
CW Skimmer System Dell Vostro 230 MT w/Q9500 |
|
Operational | PJ2T | Designed
by K8ND and W8WTS
Fabricated by W8WTS Installed on Curacao November 26, 2010 |
| Spare 500 watt power supply for PJ2T CW Skimmer System |
|
Operational | PJ2T | East bedroom, right closet, right shelves |
|
PC17
Compaq P3/933 |
Inop - Power Supply | PJ2T | Bought Feb 2004.
Taken to Curacao in March 2004 by W1MD.
PS dead Feb 2009. Spare parts for PC18. Junked 7 February 2014 |
|
|
PC8
PJ2T-CPQ450-NO2 |
Inop | PJ2T |
MODEM installed March
2004. New power supply installed 2 February 2006.
Dead Feb 2009. Spare parts. Junked 7 February 2014 |
|
|
PC14
PJ2T-CPQ450-NO3 |
Inop |
PJ2T Spare parts source |
Notes New power supply installed 2 February 2006 |
|
|
Shovic PC
|
Inop |
PJ2T In West bedroom. |
Brought
to Curacao March 2006.
New power supply installed
September 2008. Inop
Feb 2009. |
|
| Tripp
Lite USA-19HS Keyspan USB - COM port Adapter (Five each at PJ2T.) |
Operational | PJ2T and Idaho | Click here for product info. | |
| KDM MTFX9300C power supply for Dell Inspiron 560 | Spare | Operational | PJ2T | Bought and taken to Curacao November 2012 |
| Bestec TFX0250D5W power supply for Dell Inspiron 560 | Spare | Operational | PJ2T | Bought and taken to Curacao November 2012 |
| 3 Com
SuperStack II Hub 10 (NW0L) SN 0301/7TAR245593 |
Discarded | PJ2T | In
reserve in Radio Closet. Needs two new cooling fans, 12V 4 x 4 x 1.3 cm thick. Adda Corp Model AD0412MB-G70 |
|
| 3 Com
SuperStack II Switch 1000 (12 ports) (NW0L) SN 7WLR055281 |
Operational | PJ2T | In reserve in Radio Closet. | |
| 3 Com SuperStack II Switch 610 (24 ports) (KSU Office) SN 0200/ 7B4V3942EDO | Operational | W0CG | Transported to Curacao July 2008 | |
| 3 Com SuperStack II Switch 610 (24 ports) (NW0L) SN 0307 / 7B4V47664C8 | Inop - Discarded | PJ2T |
In
service for DSL effective February 2006. Installed two new cooling fans 26 Mar 2006. Papst 12V 4 x 4 x 2 cm thick. (Mouser P/N 5912-412) Blew (literally) during May 2007 KC2PZ visit. In closet as spare parts. |
|
| 3Com
LinkBuilder FMS II (24 ports) SN 0300 / 7GWV216047 |
Operational | PJ2T | Acquired May 2007 by K8ND. Taken by W0CG 4 July 2007 and installed OK. | |
| 3Com SuperStack II Switch 1000, 24 port SN 7WKR022911 | Operational | PJ2T | Acquired by K8ND June 2007, transported September | |
| 3Com SuperStack II Switch 1000, 12 port SN 7WLR074341 | Operational | PJ2T | Acquired by K8ND June 2007, transported Oct 2007 | |
|
Cisco Business CBS250-24T-4G Smart IP Switch; 24
port GE, 4x1GSFP (CCC purchase) |
Below Station 2 | Operational | PJ2T | Bought by W0CG August 2022, transported by K8ND, installed W0CG October 2022 |
| Netgear WGR614 v6
54 MBPS Wireless Router SN 16625A7C08725 |
Operational | W0CG | In reserve, removed from service November 2006 | |
| Netgear WGR614 v6
54 MBPS Wireless Router SN 16625A7W12901 |
Operational | PJ2T | In reserve Brought by W1MD, March 2006 |
|
| Netgear ProSafe
802.11g Wireless VPN Firewall FVG318 SN 1HY163A90053D |
Retired/Inop | PJ2T | Installed and configured November 2006 by K8ND | |
| ASUS RT-AC66U AC1750 Dual Band Wireless Gigabit Router | Operational | PJ2T | Bought by K8ND; transported to Curacao Jan 2013 | |
|
Comtrend Multi DSL CPE DSL MODEM (UTS Owned) Model: CT-5374 P/N 722419-131 |
Discarded July 2021 | PJ2T | Installed in EBR October 2013 by UTS | |
|
Huawei Flow DSL MODEM and Router Model: HG659 (Flow, July 2021) |
Operational | PJ2T | Installed July 2021 by Michael Demei; equipment owned by Flow/UTS | |
| Samsung SyncMaster
712N Flat Screen Monitor Model Code MJ17ASSBY |
Operational | PJ2T | Donated to CCC by John Shovic. | |
| Dell SP2309 Flat
Panel Monitor 23 inch |
Operational | PJ2T | Personal monitor for W0CG - Sunroom | |
| Dell P2419H monitor for Station 3 - bought on island at Better Deals 9 Nov 19 | Operational | PJ2T | Installed at Station 3 on 10 Nov 2019 | |
| Acer 19 inch monitor for remote station (Better Deals, October 2022) | Operational | PJ2T | Installed October 2022 | |
| Envision EN-710 17 inch NW0L monitor (CCC owned) | Operational | Trashed (good) November 2017 to warehouse building | To warehouse building | |
| Envision EN-710 17 inch monitor (W0CG) | Operational | Trashed (good) November 2017 to warehouse building | To warehouse building | |
| Envision EN-710 17 inch monitor (W8TK) | Operational | PJ2T | Surplused to VERONA | |
| Envision EN-710 17 inch monitor (W8TK) | Operational | PJ2T | Surplused to VERONA | |
| NEC LCD 1530V 15 inch flat screen monitor |
|
Operational | PJ2T - Trashed November 2017 to warehouse building | Donated by N8BJQ and transported March 2004 by K8ND. Failed 26 March 2009 - display is erratic. Tests good 7 Feb 2011. |
| SYS 1587 14 inch flat screen monitor (N1ZZ) |
|
Operational | PJ2T - Trashed November 2017 |
Failed 24
November 2009 |
| Western Digital My Book 2 TB Network Drive | Inop | Idaho | Bought July 2011. Installed 19 November 2011. Died January 2014 | |
| PC1 Compaq Pentium Deskpro (NW0L) CPQ-PII-450-2 SN: 6921CBQ4B864 128 MB RAM C: 1.6 GB NIC: Compaq NC3161 Fast Ethernet AOpen FM-56SV Soft PCI MODEM COM1, COM2, USB 10.1.1.48 255.255.255.0 |
Discarded | PJ2T Spare parts pile in East closet
|
Knocked
to floor and hard drive and CD drive damaged. New hard drive and CD drive successfully
installed January 2003. Completely inop November 2004 -- retired as spare parts
source for companion unit.
Uses Crucial CT134597 DIMM RAM |
|
| PC4 Compaq Pentium Deskpro (NW0L) CPQ-PII-450-1 SN: 6921CBQ4B025 128 MB RAM C: 1.0 GB NIC: Compaq NC3161 Fast Ethernet AOpen FM-56SV Soft PCI MODEM COM1, COM2, USB 10.1.1.47 255.255.255.0 |
Discarded | PJ2T Spare parts pile in East closet |
Notes Removed from service at Station # 4 on 7 Sept 2005. Will not start with identical power management symptoms to all other failed COMPAQs. Spare parts fource for PC1. Possible to get one good one from the two bad ones. |
|
| PC 2 IBM 266 Pentium SN 23AZF40 32 MB RAM C: 392 MB Creative Labs Model CT4740 sound card No MODEM Password: - blank - NIC: 82557 |
Discarded | PJ2T In pile to throw away from East closet |
Repaired
March 2004 by cannibalizing a 32 MB SIMM from PC6. (The original 32 MB SIMM is bad.) May
need a new video adapter card. Tests good on network. Located in open closet of East
bedroom. Dead November 2004. Cannibalization parts source for its companion (PC2). Junked 13 Nov 2005. |
|
| PC 6
(Superceded by new PC 6) PJ2T-IBM-266 Pentium SN 1565085IU23R4036 32 MB RAM C: 1.6 GB COM1 NIC USB No MODEM 10.1.1.104 255.255.255.0 |
Discarded | PJ2T In pile to throw away from East closet |
Won't
boot -- 10 July 2003 Nov 2004: Boots and starts, but no video output. Has new RAM Nov 2004. Junked 13 Nov 2005. |
|
| PC7
PJ2T-P3-450 Pentium
(CCC owned) |
Inop | PJ2T
Formerly awaiting pickup for long-term loan to Verona for PacketCluster node. |
Generates relatively
severe RFI noise. Problem is much less when monitor is plugged into another power strip.
Try K8GT Corcom noise filters (in radio closet.)
Motherboard inop. Junked for PC3 spare parts 14 Feb 2009. |
|
| NEC MultiSync LCD1530V flat panel monitor (K8ND) | Discarded | PJ2T trashed November 2017 | Donated by
K8ND Photo Failed November 2005. |
|
|
Foscam Indoor Camera Model R2V1, Ver 1.0 (November 2016) (W8WTS) |
East Bedroom toward back yard | Operational | PJ2T |
MAC Address 00626E67C0EC; admin, blank DDNS jx0706 SN: FIOFS1604002739 |
|
Foscam Outdoor Camera Model FT9900P V2/FI9800P V1.8 (November 2016) (W8WTS) |
Ocean Pavilion view | Inop - Discarded | PJ2T | Installed 28 Nov 2016 by W8WTS |
| Item | Where Currently Installed | Rotation | Status | Notes |
| 2 el 40 Yagi | Europe Tower, 107 ft | Rotatable on Mast | Operational | Cush-Craft 40-2CD |
| 5 el 20 Monoband Yagi | Europe Tower, 95 ft | Fixed Europe | Operational | Modified Hy-Gain 205-CAS, rebuilt November 2006. Notes |
| 5 el 15 Monoband Yagi | Europe Tower, 87 ft | Fixed Europe | Operational | Modified Hy-Gain
205-CAS, adapted for 15 meters, rebuilt November 2006. Notes |
| 5 el 10 Monoband Yagi | Europe Tower, 82 ft | Fixed Europe | Operational | Built from Hy-Gain components, rebuilt September 2006. |
| 3 el 10, 15, 20 Triband Yagi | Europe Tower, 45 ft | Fixed South America | Operational | Cush-Craft A-3S Notes |
| 5 el 6 Monoband Yagi | US/JA Tower, 85 ft | Rotatable on Mast | Operational | Cush-Craft
stock antenna, modified January 2011 Notes |
| 3 el 10, 15, 20 Triband Yagi | US/JA Tower, 80 ft | Rotatable on Mast | Disassembled, all parts still at PJ2T |
Mosley CL-33 Notes |
| Force 12 C-3E/H Triband Yagi | Top of US/JA Tower, 80 ft | Rotatable on mast | PJ2T |
Force 12
C-3E/H Notes Manual |
| Bencher Skyhawk Trapless Tribander (K2PLF) | Ridge Tower | Fixed Europe | PJ2T |
Donated May 2013 by K2PLF Placed in service September 2013 |
| Bencher Skyhawk Trapless Tribander (K9SG) | Side mounted at top of Europe Tower | Fixed Europe | PJ2T |
Donated May 2018 by K9SG Placed in service December 2018 |
| 5 el 20 Monoband Yagi | US/JA Tower, 70 ft | Fixed US/JA | Operational | Modified
Hy-Gain
205-CAS, rebuilt November 2007. Notes |
| 5 el 15 Monoband Yagi | US/JA Tower, 62 ft | Fixed US/JA | Operational | Custom Built from LTA Parts, rebuilt July 2007. Notes |
| 5 el 10 Monoband Yagi | US/JA Tower, 55 ft | Fixed US/JA, Top of Stack | Operational | Cush-Craft XM-10G |
| 5 el 10 Monoband Yagi | US/JA Tower, 32 ft | Fixed US/JA, Bottom of Stack | Operational | Cush-Craft XM-10G |
| 3 el 12, 17 Dualband Yagi | WARC Tower | Rotatable on Mast | Operational | Cush-Craft A-3WS |
| 4 el Triband Yagi | Europe Tower (formerly on Ridge) | Fixed Pacific | Operational | Mosley TA-34XL |
| 80 meter dipole | Ridge Tower | Broadside to Europe | Operational | Installed Oct 2009 in breadboard. Put on 40 ft mast February 2011. Rebuilt Feb 2017. Notes |
| 30 Meter Inv Vee | WARC Tower | Omnidirectional | Operational | Rebuilt with good wire September 2013 |
| 40 Meter Inv Vee | US/JA Tower | Omnidirectional | Operational | Notes |
| 80/75 US/JA Two Element Boom and Array | US/JA Tower | Fixed US/JA | Operational | Notes Tuning Manual (K6AM) |
| 80/75 3 el Delta Loop Beam | Europe/US Tower | Europe | Operational | |
| 160 Inverted L | WARC/Europe Tower | Omnidirectional | Operational | Totally rebuilt September 2013. New wire and rope. |
| Beverage US/JA | Ground Mounted | US/JA | Operational, to Ridge October 2019 | Notes |
| Beverage Europe | Ground Mounted | Europe | Operational, modified February 2022 | Notes |
| US/JA Tower, 80 ft Rohn 45 | Notes Painting Schedule | |||
| Europe Tower, 100 ft Rohn 55 | Notes Painting Schedule | |||
| WARC Tower, 56 ft Aluminum | Notes | |||
| DX Engineering RX Four-Square | Ground Mounted | Four compass points | Operational | Notes |
| Ridge Tower, 20 ft Rohn 25 | Notes |
| Item | Currently in Use at Station Number: | Status | Location | Notes |
| Top Ten Band Decoder (1) (CCC owned) IBS-1 | 1 | Operational | PJ2T | Has CCC decal on the bottom (front). Manual FM-6 Relay Manual |
| Top Ten Band Decoder (2) (CCC owned) | 2 | Operational | PJ2T | Unreliable with some transceivers March 2011. Manual FM-6 R |
| Bandmaster III, Array Solutions | 1 | Operational | PJ2T | Installed 22 November by K8ND and W8WTS Manual |
| Yaesu FH-2 Remote Keypad for voice keying; quantity 4 | 1, 2, 3, 4 | Operational | PJ2T | Nbr 4 (spare) is in Radio Closet, "FT-2000 Accessories" box. |
| Top Ten DX Doubler | Operational | W0CG | On top of Radio Closet -- has set of Yaesu cables | |
|
RigExpert AA-54 Antenna
Analyzer (K2PLF) |
Operational | PJ2T | July 2014. Click here for invoice. | |
| RAS 8x2 AY Technologies receive antenna switch box and keypad controllers | 1, 2 | Operational | PJ2T | Installed September 2005 with all associated cabling and wiring by W0CG |
| RAS 8x2 AY Technologies receive antenna switch box and keypad controllers | 3, 4 | Operational | PJ2T | Installed behind XCVR 3 with all associated cabling and wiring by W0CG |
| RemoteRig RRC-1258 Mk II | 4 | Operational | PJ2T | Mfd by www.microbit.se and configured and installed by KB7Q |
| Microbit Remoterig WiFi Interface 1258-N | Operational | Idaho | Donated by KB7Q December 2015 | |
| Astron RS-12 supply (W0CG) SN 8807007 | 1 | Operational (Needs new switch) | PJ2T | Supports RigRunner at Station #1 and runs Top Ten devices band decoder, and three stack boxes. |
| Astron SS-50M switching supply, SN 2019070008 | 1 | Operational | PJ2T | Placed in service new November 2019. |
| Astron SS-30M switching supply, SN 2017010025 | Operational | PJ2T | Placed in service new November 2019. | |
|
Astron SS-30M switching
supply, SN 205070050 (N7IR) |
Operational | PJ2T | Spare March 2022 | |
|
Astron RS-35M supply (K4LT) SN 96090349 |
Operational | PJ2T | Transported to Curacao 5 Sept '13 by W0CG | |
| Power Designs Inc. Model 5015T Variable Voltage Bench Supply | Operational | K8ND | 0
- 50V, 0 - 1.5A
K8ND will take to island November 2012. |
|
| RigBlaster (W8TK) | Operational | PJ2T | In Radio Closet | |
| Palstar DL2K Dummy Load (W8TK) | Operational | PJ2T | In service on W9NJY shelf as safe load for triplexer. | |
| Drake SSR-1 receiver SN 7740302 (W8TK) | Operational | PJ2T | East bedroom closet | |
| RigBlaster Pro (N1ZZ) | 1 | Operational | PJ2T | |
| Elecraft XG2 RX Test Generator | Operational | Bought from K6AM March 2013. | ||
| W5XD MultiKeyer (W8TK) | Operational | PJ2T | Replaced with WinKeyUSB at Station 1, 11 July 2006 | |
| WinKeyUSB Keyer # 1 | 1 | Installed 11 July 2006 on PC 20. | ||
| WinKeyUSB Keyer | Operational | Idaho | Donated by KB7Q Dec 2015 | |
| WinKeyUSB Keyer | Operational | Idaho | Donated by NA2U Dec 2015 | |
| WinKeyUSB Keyer | Operational | Idaho | Donated by N7IR Dec 2015 | |
| Astron RS-50A supply
(CCC owned) (PJ9JT) |
1 | Operational | PJ2T | Supports RigRunner
at Station #1 Repaired 17 Feb 2006 -- NP2L, N1ZZ (New regulator board) New power switch Nov 2017 |
| Astron RS-35A (W8TK) | 2 | Operational | PJ2T | Supports RigRunner at Station #2
Comes on but no DC output, Oct 09. Repaired bad board trace Oct 2009. Returned to States Sept 10 |
| Astron RS-20A SN 9212117 (W8TK) |
Operational | PJ2T | Fuse: 5A 3AG Put in service at Stn 2 Rigrunner Oct 2009. Spare Oct 2015 |
|
| Astron RS-35M SN 204060076 (W8TK) |
Operational | PJ2T | Donated January 2006, W8TK Transported to Curacao Feb 2006 by N8LGP Fuse: 8A 3AG |
|
| Astron SS-30M Switching Power Supply (KB7Q) SN203100048 | 2 | Operational | PJ2T | Donated by KB7Q 25 December 2015 |
| Astron SS-30M Switching Power Supply (N7IR) SN208080028 | 3 | Operational | PJ2T | Donated by N7IR January 2016 Notes |
| Radio Shack 22-510 Switching Power Supply 25 amp (W9JUV) | In reserve | Operational | PJ2T | |
| Power Designs Inc. Model 5015T variable voltage and current power supply (W8AV) | Operational | PJ2T | Brought by K8ND Nov 2012 | |
|
micro STACK Control Box - 20 meters SN 277 (DL8OBQ) |
1 | Operational | Idaho | Donated by DL8OBQ October 2014 |
|
micro STACK Control Box - 15 meters SN 278 (DL8OBQ) |
1 | Operational | Idaho | Donated by DL8OBQ October 2014 |
|
micro STACK Control Box - 10 meters SN 244 (DL8OBQ) |
1 | Operational | Idaho | Donated by DL8OBQ October 2014 |
| Stackmatch - 20 meters | 1 | Operational | PJ2T | StackMatch Notes
DC recabled October 2007. |
| Stackmatch - 15 Meters | 1 | Operational | PJ2T | StackMatch Notes
DC recabled October 2007. Switch box board replaced 15 Sept 2010 -- old one was pulling down DC supply voltage. Used new assembly donated by WX0B. Moved into shack Sept 13. |
| Stackmatch - spare | Operational | PJ2T |
StackMatch Notes
DC recabled November 2007. Diagram Moved into shack Sept 2013. Repaired Fall 2014 by K6AM |
|
| Stackmatch - spare | 1 | Operational in use on 10 meters | PJ2T | StackMatch Notes Board burned - discovered September 2003, new board obtained from WX0B, transported to Curacao November 2003 |
| Stackmatch - 10 Meters (WB9Z) |
Operational | PJ2T | StackMatch Notes Vendor's Stackmatch Troubleshooting Notes Donated by WB9Z December 2005. |
|
| MFJ Voice Keyer (WB9Z) | Operational | PJ2T | On shelf above radio closet | |
| MFJ-434B Voice Keyer (WB9Z, Feb 2010) | Operational | PJ2T | On shelf above radio closet | |
| MFJ-434B Voice Keyer (N0YY, October 2015) | Operational | PJ2T | On shelf above radio closet | |
| MFJ TNC (W8TK) | Untested and uninstalled | In A/C duct at Signal Point | In duct | |
| AEA PK-232MBX TNC (W8TK) | Operational | PJ2T | On shelf above Radio Closet | |
| W3NQN Bandpass Filter Panel | 1 | Operational | PJ2T | Built by W0CG. DC rotary switch replaced March 2003 by N8NR. Spare switches in radio closet. |
| Daiwa CN-720 SWR Meter | Operational | PJ2T | Donated by W8TK | |
| MFJ-870 1.6 - 60 MHz Peak Reading SWR/Wattmeter (N7WA) | Operational | PJ2T | Donated by N7WA November 2013 | |
| Autek WM 1 Computing Wattmeter (1) (W8TK) | Operational | PJ2T | Donated by W8TK Repaired by K6AM 24 December 2015, N7IR February 2022 |
|
| Autek WM 1 Computing Wattmeter (2) (W8TK) | 2 | Operational | PJ2T | Donated by W8TK
Hard-wired to RigRunner power source 15 Feb 2007. |
| Autek WM 1 Computing Wattmeter (3) (W8TK) | 3 | Operational | PJ2T | Donated by W8TK
Installed 26 Feb 2007. Repaired April 2017 N7IR |
| Autek WM 1 Computing Wattmeter (4) (W8TK) | Operational | PJ2T | Donated by W8TK Hard-wired to RigRunner power source. |
|
| Autek WM 1 Computing Wattmeter (5) NM2O | Operational | PJ2T | Donated by NM2O November 2013; atop Radio Closet | |
| Autek WM 1 Computing Wattmeter (6) N7IR | Operational | PJ2T | Donated by N7IR September 2021 | |
| Autek WM 1 Computing Wattmeter (7) K4JC | Operational | PJ2T | Donated by K4JC September 2021 | |
| Autek WM 1 Computing Wattmeter (8) | 4 | Operational | PJ2T | March 2022 |
| Autek WM 1 Computing Wattmeter (9) K4JC | Operational | PJ2T | May 2022 (Hamvention) | |
| W8WTS Unum Transformers | Operational | K8ND | Fabricated December 2005. Data Sheet | |
| Top Ten Devices Six Way Coax Switch Box (1) (N8BJQ) | Operational | PJ2T | On shelf above radio closet | |
| Top Ten Devices Six Way Coax Switch Box (2) (N8BJQ) | Operational | PJ2T | On shelf above radio closet | |
| Bencher YA-1 Low Pass Filters | 1, 2, 3, 4, 5, 6 | Operational | PJ2T | Permanently mounted to masonry wall or table |
| Bencher YA-1 Low Pass Filters | 6, 7, 8 | Operational | PJ2T | Used backup filters on shelf above radio closet. |
| DX Engineering DXE-FCC050-H05A Feedline Current Choke (K8ND) | Operational | PJ2T | In original box over Radio Closet; donated December 2013 | |
| Timewave DSP-9 | Operational | PJ2T | In Radio Closet | |
| Startek frequency counter | Operational | PJ2T | In Radio Closet | |
| Curtis Keyer (W8TK) | 4 | Operational | PJ2T | |
| Curtis Keyer (W8TK) | 2 | Operational | PJ2T | |
| Logikeyer (W8TK) | Operational | PJ2T | ||
| KC Keyer | Operational | PJ2T | ||
| KC Keyer | Operational | PJ2T | ||
| Rigrunner DC Distribution Strip | 1 | Operational | PJ2T | Donated by N1ZZ |
| Yamaha CM500 Boomset (August 2012) | Operational | Idaho | Invoice | |
| Rigrunner DC Distribution Strip | 2 | Operational | PJ2T | Donated by N1ZZ |
| Rigrunner DC Distribution Strip | 3/4 | Operational | PJ2T | Donated by N1ZZ |
| MFJ Differential T Tuner | Operational | PJ2T | Shelf above west closet | |
| Ameritron RCS-8V remote coax switch (2 each) | Operational | PJ2T | Shelf above west closet | |
| Ten Tec 252 Mo DC power supply | Operational | PJ2T | Shelf above west closet | |
| Samtek 12 volt switching power supply (K8ND) | 3 | Operational | PJ2T | Supporting the Omni VI at Station # 3 |
| Ridge high power remote coax switch (W9NJY) | Operational | PJ2T | Designed and built by W9NJY July 2013 | |
| Ameritron RCS-4 remote coax switch + spare control head (K8MFO) | Operational | PJ2T | Installed on Ridge tower 17 July 2009. | |
| Ameritron RCS-4 remote coax switch (K9SG donation) | Operational | PJ2T | In reserve in West bedroom. | |
| MFJ 259 SWR Analyzer (NP2L) | Operational | PJ2T | Radio closet Repaired by K6AM (again) May 2014 | |
| MFJ 259B(2) SWR Analyzer (WI9WI) | Operational | PJ2T | Donated by WI9WI Feb 2018 | |
| Equipment Fuses | PJ2T | Click here for detailed inventory | ||
| 1/4 wave 20 meter shorted coax stub | Operational | Idaho | Donated by KB7Q Dec 15 | |
| 1/4 wave 40 meter shorted coax stub | Operational | Idaho | Donated by KB7Q Dec 15 | |
Click here for general maintenance notes on
rotors.
PJ2T rotor wiring diagrams
| Item | Current Usage: | Status | Location | Notes |
| CCC Rotor 1: Tailtwister rotor (N6HR SK) | Spare | Operational | PJ2T | Manual Notes Replaced 1 March 2006 and returned to CATS for rebuild. Repaired and returned to Curacao June 2006. |
| CCC Rotor 2: Ham III rotor (K8MFO) |
On WARC tower Feb 2020 | Operational | PJ2T | Manual Notes |
| CCC Rotor 3: Ham IV rotor (N8BJQ) |
Spare for US/JA | Operational | PJ2T | Has quick connect and temporary terminal strip on tower Manual Notes |
| CCC Rotor 4: Ham IV rotor |
Spare for US/JA | Operational | W8AV to CATS; shipped to W9NJY in December 2012 for transport to island in February 2013. In spares at station Feb 2013. | Removed March 2012 for repair. Manual Notes |
| CCC Rotor 5: Tailtwister rotor (W9JUV SK) |
Installed in US/JA tower 25 October 2019 | Operational | PJ2T | Manual Notes Installed 1 March 2006 |
| CCC Rotor 6: Ham IV rotor (N8ME) |
Spare for WARC | Operational | PJ2T | Notes |
| CCC Rotor 7: Ham IV rotor (W8TK) |
Spare on closet shelf | Operational | PJ2T | Rebuilt by CATS in May 2002; has quick connect. Manual Notes |
| CCC Rotor 8: Ham IV rotor (K8NZ) |
Spare for US/JA | Inop as reported by Brett | VERONA - on loan | Donated by K8NZ in August 2003. Manual Notes |
| CCC Rotor
9: Tailtwister rotor (K8NZ) |
On
100 foot tower Dec 2018 Removed Oct 27, 2021 |
Inop | Junked April 2022, unrepairable | Donated by K8NZ in August 2003. Manual Notes |
|
CCC Rotor 10 Tailtwister rotor (CCC) |
Spare | Inop | PJ2T | Bought Sept 2018 Spokane hamfest; brake works but no rotation |
|
CCC Rotor 11 Tailtwister rotor (N7IR) |
Spare | Operational | PJ2T on Europe tower | Bought June 2020 in Phoenix by N7IR Notes |
|
CCC Rotor 12 Tailtwister rotor (N7IR) |
Spare | Operational | PJ2T | Donated June 2020 by N7IR. Inop, needs CATS overhaul Notes |
|
CCC Rotor 13 Tailtwister rotor (W0NB via NR0X) |
Spare | Probably operational | W0CG | Donated by NR0X, from W0NB QTH. Retained at W0CG for evaluation prior to shipping. |
|
CCC Rotor 14 Tailtwister (VE4GV) |
Spare | Operational | PJ2T, pending installation into Europe tower | Notes |
|
CCC Rotor 15 Tailtwister (VE4GV) |
Spare | Operational | PJ2T | Notes |
|
CCC Rotor 16 Tailtwister (K9JF) |
Spare | Operational | Idaho | Notes |
| VERONA Rotor | Spare | Operational | W0CG | Notes |
| CCC Rotor Control Box 1: (no label, black face), with Rotor-EZ mod |
CL-33/6 yagi | Operational | PJ2T | |
| CCC Rotor Control Box 3: Ham IV/CD-45-II Control, Series 82280, (black face), with Rotor-EZ mod |
WARC yagi | Operational | PJ2T | |
| CCC Rotor Control Box 4: 40 Yagi: Hy-Gain Tailtwister Control, Series (label unreadable, black face), with Rotor-EZ mod |
Spare | Operational | VERONA - on loan | Notes |
| CCC Rotor Control Box 5: CDE Transmit/Receive Direction Control, Model Ham III/CD-44, Series Dec 1977, gold face, has no brake release switch (by design). |
Spare | Operational | PJ2T | Tested July 2003 by K4LT, needs a panel lamp. |
| CCC Rotor Control Box 6: CDE Transmit Receive Direction Control, Model Ham II/CD-44, Series 432, gold face, has brake release. |
Spare | Operational | PJ2T | Looks a bit rusty. This is the original PJ9JT control box. |
| CCC Rotor Control Box 7: Hy-Gain Tailtwister Control, Series (87226), black face), with Rotor-EZ mod |
Spare | Operational | PJ2T | Donated by N8NR |
| CCC Rotor Control Box
8: (black face). |
Spare | Operational | PJ2T | Bought at Dayton May 2009. N8NR installed point and shoot mod. |
| CCC Rotor Control Box
9: Hy-Gain Tailtwister Control, Series (93046, black face), with some kind of point and shoot mod |
Spare | Operational | W0CG for shipment to PJ2 | Donated by N7IR |
| CCC Rotor Control Box
10: Hy-Gain Tailtwister Control, label obscured |
Spare | Operational | W0CG for shipment to PJ2 | Donated by N7IR |
| CCC Rotor Control Box
11: Hy-Gain Tailtwister Control, label obscured, SN 1614 |
Spare | Operational | Idaho | Donated by K9JF |
|
VERONA Rotor Control Box (black face) |
Spare | Operational | PJ2T | Repaired by CATS May 2014 and returned to inventory in Curacao October 2014. |
| PJ2T Tube Number and Type | Currently in Use in Amplifier: | Status | Location | Notes |
| 1 8874 |
Alpha 78 (W8TK) |
Alpha factory | Bad. Discarded July 2009. | |
| 2 8874 |
Alpha 78 (W8TK) |
Alpha factory | Bad. Discarded July 2009. | |
| 3 8874 |
Alpha 78 (W8TK) |
Alpha factory | Bad. Discarded July 2009. | |
| 4 8874 |
Alpha 76PA (WI9WI) |
PJ2T | ||
| 5 8874 |
Alpha 76PA (WI9WI) |
PJ2T | ||
| 6 8874 |
Alpha 76PA (WI9WI) |
PJ2T | ||
| 7 8874 |
Alpha 76CA (Arizona) |
PJ2T | ||
| 8 8874 |
Alpha 76CA (Arizona) |
PJ2T | ||
| 9 8874 |
Alpha 76CA (Arizona) |
PJ2T | Bad: Discarded October 2009. | |
| 10 8874 |
Spare | New February, 2004 | W8TK | Feb 2004 Test report Given to W8TK July 2009. |
| 11 8874 |
Spare | New February, 2004 | W8TK | Feb 2004 Test report Given to W8TK July 2009. |
| 12 8874 |
Spare | New February, 2004 | W8TK | Feb 2004 Test report Given to W8TK July 2009. |
| 13 8874 |
Alpha 76CA (Arizona) |
New June, 2004 | PJ2T | June 2004 Test report Installed in Arizona linear Oct 2009. |
| 14 8874 |
Spare | New June, 2004 | PJ2T | June 2004 Test report |
| 15 8874 |
Spare | New June, 2004 | PJ2T | June 2004 Test report |
| 16 3CX1200A7 |
AL-1200 (1) | New August, 2003 | PJ2T | Installed September 2003 |
| 17 3CX1200A7 |
Spare | Came in AL-1200 (1) | PJ2T | Removed from AL-1200 and replaced with good tube. Output about 80%. |
| 33 3CX1200A7 |
AL-1200 (2) | Came with AL-1200 (2) | PJ2T | New tube came as a spare with amp bought February 2009. Installed immediately after was found that the original tube was dead. |
| 34 3CX1200A7 SN WCQ-0003 |
AL-1200 (3) | Came with AL-1200 (3) | PJ2T | New tube came in amp bought December 2009. |
| 35 3CX1200A7 |
Spare | Bought from VY1EI | PJ2T | Bought new from VY1EI on E-Bay October 2010. Tested good 3 Dec 2010 and placed in storage. |
|
36 3CX1200A7 |
Discarded Mar 2021 | Bought on EBay by K8ND September 2012 | PJ2T | Tests good at W8AV 1 November 2012. N0KE took it to Curacao. Discarded 3 Mar 2021 dead short in AL-1200 (5). |
|
37 3CX1200A7 |
Spare | Came with AL-1200 (5) | PJ2T | Unusable - runs very, very hot per K8LEE Oct 2013. In EBR Box. Tests 100% good Mar 2018. Blown shorted March 3, 2021. |
| 38 3CX1200A7 |
Spare | Bought by K8ND March 2015 | PJ2T Box 14 WBR dct | Tested good by W8AV Sept 2015 |
| 39 3CX1200A7 |
In AL-1200 (5) | Bought by N0YY March 2016 from W9KNI new in box | PJ2T | Tested good by W8AV Sept 2015. Installed in AL-1200 (5) 3 Mar 2021. |
| 40 3CX1200A7 |
In AL-1200 (6) | Bought with amplifier March 2018 | PJ2T | |
| 41 3CX1200A7 |
In AL-1200 (7) | Obtained with amplifier September 2019 | PJ2T | K2PLF says the tube is soft. |
| 48 3CX1200A7 |
Spare | Obtained in Europe by DL8OBQ, July, 2023 | PJ2T | Tests good Nov 2023. |
| 18 4CX1600B |
Titan II | New September, 2005 | PJ2T | Bought from St Petersburg Tested good -- full output by Ten-Tec factory July 2005. This tube installed in Titan II October 2005. Full output. Old tube (Number 20) in reserve as spare -- good output. Retired to States 1 Dec 2009 along with Titan II. |
| 19 4CX1600B |
Spare | New September, 2005 | PJ2T | Bought from St Petersburg Tested good -- full output by Ten-Tec factory July 2005. Retired to States 1 Dec 2009 along with Titan II. |
| 20 4CX1600B |
Spare for Titan II | Removed from service October, 2005 | PJ2T | About 80% rated output at the time of removal.
Retired to States 1 Dec 2009 along with Titan II. |
| 21 GU-91B |
Spare for Titan II | PJ2T | Also have chimney for this
Retired to States 1 Dec 2009 along with Titan II. |
|
| 22 3CX800A7 |
Front socket, Titan I Feb 2018 | New September, 2005. Feb 2018 test: 600 w on LV, 1200 W on HV, then grid current spikes. | PJ2T | Installed September 2005. Removed from LK-800 25 January 2005. |
| 23 3CX800A7 |
Spare | Original PJ9JT tube. Feb 2018 test: 500 W LV, 1 KV HV. | PJ2T | Removed from LK-800 25 January 2005. |
| 24 3CX800A7 |
Titan I | VERONA old tube | Discarded | |
| 25 3CX800A7 |
Titan I | VERONA old tube | Discarded | |
| 26 3CPX800A7 |
Rear socket, Titan I Feb 2018 | New. Feb 2018 test: 1100 W LV, 1400 W HV. | PJ2T | Bought from Jan Robbins December 2005 Tests good, full output, 18 Dec 2005. Installed in LK-800 7 Feb 2013. |
| 27 3CPX800A7 |
In LK-800 left socket Feb 2018. | New. Feb 2018 test: 1000 W with just this tube in LK-800. Operates normally. Fused to chimney. | PJ2T | Bought from Jan Robbins December 2005 Tests good, full output, 18 Dec 2005. Installed in LK-800 25 January 2006. Burned but left in LK-800 7 Feb 2013; partial output. In left socket. |
| 28 3CPX800A7 |
Spare | Burned, fused to chimney. Not tested Feb 2018. | PJ2T | Bought from CB source December 2005 Tests good, full output, 19 Dec 2005. Installed in LK-800 25 January 2006. Removed 7 Feb 2013, fused to lower chimney. May be good last-ditch spare. |
| 29 3CPX800A7 |
In LK-800 right socket Feb 2018. | New. Feb 2018 test: 700 W LV, 1300 W HV in LK-800, this tube alone. Not fused to chimney. | PJ2T | Bought from Jan Robbins February 2006 Tests good, full output, 20 February 2006. Installed in Titan I 22 Nov 2013. Feb 2018 makes 1300 w this tube alone at high HV. |
| 30 3CPX800A7 |
Spare | New. Feb 2018 test: 1100 W LV, 1600 W HV, very good condition. | PJ2T | Bought from Jan Robbins February 2006 Tests good, full output, 20 February 2006. Installed in Titan I 22 Nov 2013 |
| 31 3CPX800A7 |
Spare | New. Never installed. Feb 2018 test: not tested. Needs filaments to be seasoned. | PJ2T | Bought from Jan Robbins February 2006 Tests good, full output, 20 February 2006. |
| 32 3CX800A7 |
Spare | Feb 2018 test: 500 W LV, 1000 W HV in Titan I rear socket. | PJ2T | Very soft but operational tube removed from W0CG Titan I after lightning damage. Good tube for troubleshooting in LK-800. |
| 33 3CX800A7 |
Spare | Feb 2018 test: 1100 W LV, 1600 V HV, very good condition. | PJ2T | Removed from Titan 425 Nov 2013 |
| 34 3CX800A7 |
Spare | Feb 2018 test: 500 W LV, 1000 W HV. | PJ2T | Feb 2018 this tube alone makes 500 watts at low HV, then grid current spikes above 30 W drive. |
| 40 should
renumber to 43 3CX1200A7 |
Spare | Bought used May 2019 from K6AW | PJ2T | |
| 35 3CX1200A7 |
Spare | Bought used Dec 2013 from W2CQM/3 | PJ2T | W9XT Test Report |
| 36 3CX1200A7 |
Spare | Bought used Dec 2013 from W2CQM/3 | PJ2T | W9XT Test Report |
| 44 3CX800A7 |
In HF-2500 (L) | Came in amp from NR0X August 2021 | PJ2T | |
| 45 3CX800A7 |
In HF-2500 (R) | Came in amp from NR0X August 2021 | PJ2T | |
| 46 3CX1200A7 |
Spare | Bought from ND8L May 2021 | PJ2T | Note in box says bought from Paul Webb, Clute, TX, 10/98 $450, tested full power 1500 watts in Henry 3KP. New in box. |
| 47 3CX1200A7 |
In AL-1200 (8) | Came in AL-1200 (8) from PJ2BR | PJ2T | |
| 50 3CPX800A7 |
Spare | Bought January 2024 from K3AC | PJ2T | |
| 51 3CPX800A7 |
Spare | Bought January 2024 from K3AC | PJ2T | |
| 52 3CPX800A7 |
Spare | Bought January 2024 from N0NR | PJ2T | |
| 53 3CPX800A7 |
Spare | Bought January 2024 from N0NR | PJ2T | |
